Fully Automatic Aluminum Foil Container Making Machine with 35-70 Strokes/Min Speed and C-Frame Hydraulic Press

LK-T63 Aluminum Foil Container Making Machine is a high-speed press line designed for smooth wall aluminum foil containers. Three-cavity mold is the recommended configuration. Also compatible with wrinkle wall molds.

• Design speed range: 35-70 strokes/min
• Actual operating speed: approximately 50 strokes/min
• With three cavities, output is roughly 9,000-12,000 pieces per hour

• C-type frame structure
• Lithium-based grease lubrication, non-circulating oil system
• Mold change: lifting arm with hydraulic pump allows one person to complete change in approximately 15 minutes
• Parameter storage: 60 mold parameter sets, recall directly when switching products
• Fault handling: automatic stop with alarm, fault location displayed on touchscreen
• Safety: machine stops automatically when safety door is opened during operation

• PLC, touchscreen, inverter: Mitsubishi
• Main motor: Innomotics
• Low-voltage components: Schneider
• Pneumatics: SMC / Airtac
• Power: 19.8KW
• Electrical: 380V / 50Hz / 3-phase

• Decoiler
• T63 press machine
• Scrap suction system
• Standard three-cavity stacker
• Scrap baler
• Scrap aspirator

• One operator per line
• Capable of 24-hour continuous operation
• Average stamping speed: 50 strokes per minute
• Automatic stop with fault display on touchscreen
• 60 mold parameter storage
• Quick mold change system

• Packaging: wooden case
• Shipping: 40ft high cube container – one line plus 4 sets of molds fit
• Warranty period: 1 year
• Technical support: lifetime

• Professional R&D of aluminum foil finished product equipment since 2010
• Fast pre-sales and after-sales service
• Overseas installation services
• One stop comprehensive service for aluminum foil product projects
• The spirit of continuous improvement and development
